HN-CG60 Oilseed Expeller / Pre-Press Machine
Roll-press crusher that adds 3–5% to total oil yield
A screw expeller that crushes and roll-presses oilseeds before roasting and hydraulic pressing. It draws off about 35–40% of the oil in a first pass and raises total plant yield by 3–5%. Standard 7.5 kW (500 kg/h), optional 11 kW (750 kg/h).
Product Overview
The HN-CG60 oilseed expeller (also supplied as model YZJ-7.5/11) sits at the front of the line. It crushes the seed and compresses it into flakes or a rough cake, cracking the oil cells and enlarging the seed’s heated surface area. Around 35–40% of the oil is released in this first pass, and the pre-pressed material then goes on to roasting and the main hydraulic press. Plants that add this stage typically see their total oil yield rise by 3–5%.
This two-stage layout — screw pre-press followed by hydraulic finishing — is the standard setup for mustard, rapeseed and groundnut in India, Southeast Asia and Africa. The machine arrives fully assembled, needs no specialist installation, and one worker operates it.
Structure & Build
Screw crushing and roll-pressing in one unit
Seeds enter the hopper and are pushed by the screw through the pressing chamber, where they are crushed, rubbed and pressed into flakes. A discharge cone at the outlet sets the gap, so you control flake thickness and the tightness of the pre-press.
Compact steel frame, V-belt drive
The whole line — motor, pressing chamber and hopper — sits on one compact steel frame. Drive runs through belts and pulleys, which cushions shock loads and is cheap to service. The machine occupies about 1 m² and moves with a forklift.
Key Performance Features
Two throughput options
The standard 7.5 kW machine handles about 500 kg/h; an 11 kW version is available for about 750 kg/h. Both run on 380 V (other voltages on request).
Works on many seeds
Rapeseed, soybean, flaxseed, Sichuan pepper seed, sesame, walnut, peanut, sunflower seed and cotton seed are all handled by adjusting the cone gap.
Low energy, low wear, quiet
A direct mechanical drive wastes little power, hardened wearing parts last a long time, and the machine runs steadily with little noise.
Ready to run, lead time 7–15 days
It ships fully assembled and tested — position it, connect power, and it starts. Orders normally leave the factory within 7–15 days.
Technical Specifications
| Model | HN-CG60 Oilseed Expeller / Pre-Press (YZJ-7.5/11) |
|---|---|
| Motor Power | 7.5 kW standard / 11 kW optional |
| Voltage | 380 V (customizable) |
| Motor Speed (7.5 kW) | 1460 r/min |
| Capacity | About 500 kg/h (7.5 kW) / 750 kg/h (11 kW) |
| Overall Dimension | 1030 × 1000 × 750 mm (103 × 100 × 75 cm) |
| Machine Weight | 174 kg |
| Pre-Pass Oil Output | About 35–40% of seed oil |
| Typical Yield Increase | 3–5% total oil yield when combined with hydraulic finishing |
| Applicable Materials | Rapeseed, soybean, flaxseed, Sichuan pepper seed, sesame, walnut, peanut, sunflower seed, cotton seed |
| Delivery | Arrives fully assembled; production lead time 7–15 days |
Applicable Materials
Rapeseed, soybean, flaxseed, Sichuan pepper (prickly ash) seed, sesame, walnut, peanut, sunflower seed and cotton seed. Recommended for mills running mustard/rapeseed and groundnut lines in India, Southeast Asia and Africa.
Typical Applications
Operation Tips From the Factory
- 1
Warm the pressing chamber for 2–3 minutes before the first feed of the day.
- 2
Best seed moisture is around 6–8% — too wet blocks the outlet, too dry produces powder instead of flakes.
- 3
Feed steadily and evenly; do not heap seed into the hopper.
- 4
Set the discharge-cone gap by material: tighten it for small seeds, loosen it for larger kernels.
- 5
At the end of a run, pass coarse bran through the chamber to clean out residual oil and meal.
- 6
Check belt tension and wear about once a month and adjust or replace as needed.
Why Buyers Choose This Machine
The pre-press earns its keep quickly: it removes 35–40% of the oil before the main press, so the hydraulic stage runs faster and the plant’s overall yield is 3–5% higher. At under 200 kg and about one square metre of floor space, it slots into an existing line with no building work.
