Fried Food Residue (KFC-Style) Oil Press
Recover oil from fried breading and food residue
A static high-pressure press for fried bread crumb and KFC-style food residue. It recovers the frying oil and turns the spent crumb into a dry, low-residual cake suitable for animal feed.
Product Overview
This press was developed for food factories and central kitchens that accumulate large amounts of oil-soaked fried residue — breaded crumbs, batter waste and KFC-style frying byproducts. At 60–75 MPa of static hydraulic pressure, it separates the residue into crude recovered oil and a dry cake with very little oil left in it.
Because pressing is static with no screw friction, no extra heat is generated and the oil is not oxidised. The recovered oil can be processed further, and the dry cake — low in residual oil — is suitable for animal feed. The same machine also presses camellia seed, rapeseed and sesame, and dewaters other kinds of sludge.
Structure & Build
390mm barrel, ~95 L per batch
The standard barrel is 390 mm in inner diameter and 800 mm high, holding about 95 L of residue per cycle. The main pressing body is built on our standard 325/365/500 platform and can be configured to whichever tonnage you need.
Multi-layer filter structure
Layered filtration inside the barrel lets oil escape from the thick paste without clogging and keeps fine particles out of the recovered oil.
Key Performance Features
Recovers frying oil
Oil that would otherwise be thrown away with the crumb is pressed out and collected.
Dry cake for feed
The low-residual cake is dry enough to handle and suitable for animal-feed use.
No friction heat
Static pressing protects the recovered oil from oxidation and keeps its value.
Multi-purpose
Also presses camellia seed, rapeseed and sesame, and dewaters various sludge materials.
Model options
Built on the 325, 365 or 500 pressing body to match your daily residue volume.
Technical Specifications
| Type | Vertical static high-pressure fried-residue oil press |
|---|---|
| Barrel Inner Diameter | 390 mm |
| Barrel Height | 800 mm |
| Batch Volume | About 95 L |
| Working Pressure | 60–75 MPa |
| Outputs | Crude recovered oil + low-residual dry cake (animal feed) |
| Model Configuration | 325 / 365 / 500 pressing body, customizable |
| Other Applications | Camellia seed, rapeseed, sesame pressing and sludge dewatering |
Applicable Materials
Fried bread crumb and KFC-style fried food residue, batter and breading waste, plus camellia seed, rapeseed, sesame and various sludges.
Typical Applications
Why Buyers Choose This Machine
For a central kitchen or fried-food factory the residue used to be pure disposal cost. This press turns it into two usable outputs — recovered oil and dry feed-grade cake — while shrinking the waste volume that leaves the site.
